CONN RCPT 52POS 0.1 GOLD PCB
CRIMPER, INSULATION "O"
634 SERIES RIGHT ANGLE D-SUB REC
INSULATION DISPLACEMENT SOCKET C
图片仅供参考，请联系我们获取真实图片
| 类型 | 描述 |
|---|---|
| 系列: | 966 |
| 包裹: | Tube |
| 零件状态: | Obsolete |
| 连接器类型: | Receptacle, Bottom or Top Entry |
| 联系方式: | Female Socket |
| 风格: | Board to Board |
| 职位数: | 52 |
| 加载的位置数: | All |
| 俯仰交配: | 0.100" (2.54mm) |
| 行数: | 2 |
| 行距 - 交配: | 0.100" (2.54mm) |
| 安装类型: | Through Hole |
| 终止: | Solder |
| 紧固类型: | Push-Pull |
| 接触完成 - 交配: | Gold |
| 接触表面厚度 - 配合: | Flash |
| 绝缘颜色: | Black |
| 绝缘高度: | 0.197" (5.00mm) |
| 接触长度 - 后: | 0.118" (3.00mm) |
| 工作温度: | -25°C ~ 105°C |
| 材料可燃性等级: | UL94 V-0 |
| 接触完成 - 发布: | Tin |
| 配对堆叠高度: | - |
| 入口保护: | - |
| 特征: | - |
| 额定电流（安培）: | 2A |
| 额定电压: | 1000VDC |
