图片仅供参考，请联系我们获取真实图片
| 类型 | 描述 |
|---|---|
| 系列: | DF19 |
| 包裹: | Tape & Reel (TR)Cut Tape (CT) |
| 零件状态: | Obsolete |
| 连接器类型: | Receptacle |
| 联系方式: | Male Pin |
| 俯仰交配: | 0.039" (1.00mm) |
| 职位数: | 20 |
| 行数: | 1 |
| 行距 - 交配: | - |
| 加载的位置数: | All |
| 风格: | Board to Cable/Wire |
| 笼罩: | Shrouded - 3 Wall |
| 安装类型: | Board Edge, Cutout; Surface Mount, Right Angle |
| 终止: | Solder |
| 紧固类型: | Friction Lock |
| 接触长度 - 交配: | - |
| 接触长度 - 后: | - |
| 总接触长度: | - |
| 绝缘高度: | 0.057" (1.45mm) |
| 接触形状: | - |
| 接触完成 - 交配: | Gold |
| 接触表面厚度 - 配合: | - |
| 接触完成 - 发布: | - |
| 接触材料: | Phosphor Bronze |
| 绝缘材料: | Polyamide (PA), Nylon |
| 特征: | Solder Retention |
| 工作温度: | -35°C ~ 85°C |
| 入口保护: | - |
| 材料可燃性等级: | UL94 V-0 |
| 绝缘颜色: | Beige |
| 额定电流（安培）: | - |
| 额定电压: | 100V |
