CONN HEADER R/A 12POS 2MM
CIRCULAR MIL SPEC CONNECTOR PP P
CPS19-LA00A10-SNCSNCWF-RI0YMVAR-W1064-S
SWITCH PUSHBUTTON SPST 100MA 42V
CONN PLUG HSG FMALE 10POS INLINE
图片仅供参考，请联系我们获取真实图片
| 类型 | 描述 |
|---|---|
| 系列: | Sherlock 35363 |
| 包裹: | Bulk |
| 零件状态: | Obsolete |
| 连接器类型: | Header |
| 联系方式: | Male Pin |
| 俯仰交配: | 0.079" (2.00mm) |
| 职位数: | 12 |
| 行数: | 1 |
| 行距 - 交配: | - |
| 加载的位置数: | All |
| 风格: | Board to Cable/Wire |
| 笼罩: | Shrouded - 4 Wall |
| 安装类型: | Through Hole, Right Angle |
| 终止: | Kinked Pin, Solder |
| 紧固类型: | Locking Ramp |
| 接触长度 - 交配: | 0.145" (3.70mm) |
| 接触长度 - 后: | 0.126" (3.20mm) |
| 总接触长度: | - |
| 绝缘高度: | 0.217" (5.51mm) |
| 接触形状: | Square |
| 接触完成 - 交配: | Tin-Lead |
| 接触表面厚度 - 配合: | 78.7µin (2.00µm) |
| 接触完成 - 发布: | - |
| 接触材料: | Brass |
| 绝缘材料: | Polyamide (PA), Nylon |
| 特征: | - |
| 工作温度: | - |
| 入口保护: | - |
| 材料可燃性等级: | UL94 V-0 |
| 绝缘颜色: | Natural |
| 额定电流（安培）: | - |
| 额定电压: | - |
